2022-09-15
New design of the successful automation solution OnQ FormingSens ensures optimized real-time measurement of water weight in the forming section
- Based on many years of experience and profound know-how, Voith improves the design of OnQ FormingSens for optimized lifetime, reliability and operator friendliness
- Thanks to real-time measurement, the operator continuously receives information about the dry content in the forming section and can optimize the vacuum settings
- In combination with the OnC.Dewatering automatic vacuum control system, layer bonding in the forming section can be improved and energy requirements reduced
![Compared to the previous OnQ FormingSens, the new generation features a significantly longer service life, flexible connectivity to existing process control systems and improved mechanical stability, enabling reliable measurement results. (Left)
The focus of the new design is on a reliable, low-vibration construction, as well as a simplified electrical design. (Right) Compared to the previous OnQ FormingSens, the new generation features a significantly longer service life, flexible connectivity to existing process control systems and improved mechanical stability, enabling reliable measurement results. (Left)
The focus of the new design is on a reliable, low-vibration construction, as well as a simplified electrical design. (Right)](/corp-en/Voith_OnQFormingSens_rdax_1200x675s.jpg)
The focus of the new design is on a reliable, low-vibration construction, as well as a simplified electrical design. (Right)
The new design focuses on a solid, low-vibration construction, as well as a simplified electrical design. Among other things, Voith's experts reworked the mechanical mount so that the operator can now fine-tune the penetration depth from outside the machine via waterproof mechanical gear. The sensor holder can be flexibly positioned on various existing dewatering elements in the former. Compared to hand-held measuring devices, the permanently installed application is characterized by higher safety, as no direct contact of the operator with the forming fabrics is necessary. An improved sensor housing ensures higher long-term stability. The new generation OnQ FormingSens is installed to a nearby terminal box, which can be serviced by Voith experts via a service connection. This allows the optimized solution to be better connected to customers' existing infrastructures, such as the process control system.
Combination with OnC.Dewatering dewatering control system
Based on the measurements of OnQ FormingSens, the control loop can be closed with the fully automatic dewatering control OnC.Dewatering. The control system defines and stabilizes the dry content of each layer produced and thus significantly increases ply bond on multi-ply machines.
Further information on the automation solutions can be found here.
