Make the "EZi" torque limiting choice

SafeSet EZi

Protecting your driveline and ensuring continued productivity is our specialty. This experience and know-how obtained over the last 40 years have enabled us to provide the next generation of safety torque limiting couplings.

Send us your enquiry
SafeSet EZi | Torque limiting coupling

All benefits at a glance

    Voith benefit icon
    Proven technology
    Robust, reliable and proven technology perfected over 40 years
    Voith simplified resetting icon
    Simplified resetting
    Simplified resetting, facilitated by technical enhancements and a shear tube installation tool
    Speed and timing
    Lead and delivery times
    Improved lead and delivery times, including spare parts
    Voith gearing icon
    Mechanism design
    Release mechanism design enables peak shaving, without disengaging the coupling
    Voith benefit icon
    Real-time monitoring
    Add Dtect and monitor the status of your coupling

    Our product portfolio

      SafeSet EZi-P series, for flange to flange connections

      Size MA
      [kNm]      		 PCDmin1
      [mm]      		 Lmin2
      [mm]
      60 1.3 – 3.3 172 133
      120 4.6 – 20 250 190
      180 13.1 – 59.8 340 262
      260 39.2 – 179 489 361
      340 110 – 461 628 527
      420 171 – 788 761 585
      SafeSet EZi-P series, for flange to flange connections
      SafeSet EZi-P, used between two gear coupling halves

      SafeSet EZi-N series, for cylindrical shaft to flange connections

      Size MA
      [kNm]      		 PCDmin1
      [mm]      		 Lmin2
      [mm]      		 Shaft ø
      [mm]
      60 1.3 – 3.3 172 143 60
      90 3.2 – 12 204 198 90
      120 4.6 – 20 250 193 120
      150 8.9 – 38.9 294 235 150
      200 17.9 – 81.8 373 288 200
      SafeSet EZi-N series, for cylindrical shaft to flange connections
      SafeSet EZi-N, with lamella coupling
      Types of applications where a torque limiting coupling can be used

      SafeSet EZi-K series, for keyway shaft to flange connections

      Size MA
      [kNm]      		 PCDmin1
      [mm]      		 Lmin2
      [mm]      		 Shaft ømax3
      [mm]
      120 4.6 – 20 250 181 85
      180 13.1 – 59.8 340 251 135.5
      260 39.2 – 179 489 342 209.5
      340 110 – 461 628 497 283
      420 171 – 788 761 557 348
      SafeSet EZi-K series, for keyway shaft to flange connections
      SafeSet EZi-K, for keyway shaft with flexible coupling


      MA:  Release torque – adjustment range
      1: Minimum PCD (pitch circle diameter) depends of selected hole size
      2: Minimum L depends of selected flange thickness and type of centering
      3: Minimum shaft diameter depends on number of keys in keyway shaft

      For additional configurations, please contact your regional sales contact.
