VoreconNX

The latest in mechanical variable speed planetary gear

Efficient control of compressors and pumps

    VoreconNX

    Designed to control your motor-driven machines in the low-power range with the utmost reliability and efficiency, the VoreconNX is particularly suited to compressor applications (up to 10 MW).



    The oil and gas industry, upstream, midstream, and downstream, can benefit from the latest advances in hydrodynamic power transmission combined with variable speed planetary gearing.

    Get in touch with our experts

    All benefits at a glance

      Voith benefit icon
      10
      Economical solution for up to 10 MW
      Voith superior quality icon
      48
      48 years mean time between failure (MTBF)
      Voith efficiency icon
      8
      8% higher efficiency at partial load
      Voith integrated partner icon
      Highly competitive price
      Highly competitive technology pricing
      Voith cost reduction icon
      CAPEX reduction
      CAPEX reduction (standardized spare parts)
      Voith tool icon
      Advanced development
      Ease of maintainance

      OnCare.Health Vorecon

        Are you interested in minimizing maintenance costs and increasing the availability of your critical drivetrain? The answer, OnCare.Health Vorecon!

        Unlike other machine protection systems in the power, oil, and gas industries, OnCare.Health Vorecon is self-learning. The data diagnostic system continuously analyzes the machine’s condition and predicts future behavior through accurate signal analysis and data diagnostics.

        The self-learning diagnostic system that monitors your Vorecon’s ‘Heartbeat’ in power, oil and gas applications

        OnCare.Health - Vorecon

        How the VoreconNX works

          The VoreconNX is located in the driveline between the drive motor and the driven machine. The input shaft is connected to the planet carrier of the planetary gear. A large proportion of the input power is transmitted to the planetary gear mechanically, which means it is delivered almost loss-free.

          In front of the planetary gear, a torque converter with adjustable guide vanes is found. The torque converter pump wheel is coupled with the input shaft and diverts a small amount of input power. The diverted power is transferred to the planetary sun gear using the turbine wheel. Adjustable pump blades control the turbine wheel liquid flow together with speed. Combined power from the planet carrier and sun gear flows through the planetary gear and is transmitted to the output gear stage.



          Open view of the VoreconNX

          Find the right product for your equipment in a few simple steps

            The VoreconNX series guarantees efficient control of compressors and pump with its latest advances.

            Your application

            Mandatory fields

            (up to 20,000 rpm)
            kW

            In order for you to utilize the VoreconNX Selection Guide, please fill in the contact data required below.

            Please enter the security code

            Overview of VoreconNX

              Front view

              Selection

              Design benefits

              VoreconNX design benefits (front view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX design benefits (front view)

              Components

              VoreconNX components (front view)
              Please click on the info icons in the graphic to find out more. For changing the selection please click on the buttons on the right-hand side.
              VoreconNX components (front view)

              Instrumentation

              VoreconNX instrumentation (front view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX instrumentation (front view)

              USPs

              VoreconNX USPs (front view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX USPs (front view)

              Interfaces

              VoreconNX interfaces (front view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX interfaces (front view)

              Rear view

              Selection

              Design benefits

              VoreconNX design benefits (rear view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX design benefits (rear view)

              Components

              VoreconNX components (rear view)
              Please click on the info icons in the graphic to find out more. For changing the selection please click on the buttons on the right-hand side.
              VoreconNX components (rear view)

              Instrumentation

              VoreconNX instrumentation (rear view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX instrumentation (rear view)

              USPs

              VoreconNX USPs (rear view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX USPs (rear view)

              Interfaces

              VoreconNX interfaces (rear view)
              For changing the selection please click on the buttons on the right-hand side.
              VoreconNX interfaces (rear view)

              Key technical data

                Rated power 2-10 MW
                Input speed 1,500 rpm or 1,800 rpm
                Rated output speed Up to 16,000 rpm
                Speed range 70% - 105%
