BHS diaphragm couplings: light, flexible, powerful

    The fully developed, high-quality Voith diaphragm couplings have proven themselves particularly in turbo systems. Custom solutions and low maintenance requirements are special features that distinguish Voith diaphragm couplings for our customers. Exceptionally light and powerful, they can be flexibly combined with existing energy sources.

    FREE CONSULTATION VOITH SERVICE

    J.M. Voith SE & Co. KG

    Hans-Böckler-Straße 7
    87527 Sonthofen, Germany
    Tel.  +49 8321 802 825

    Contact us

    Features & advantages of BHS diaphragm couplings

      Discover the advantages of our diaphragm couplings:

      1500000
      1500000
      Torque of up to 1,500,000 Nm
      80000
      80000
      Speeds of up to 80,000 rpm
      70
      70
      Power transmission of up to 70 MW

      • Long service life
      • Custom-tailored to your individual requirements
      • Highest reliability avoids unplanned downtimes of the drive train
      • Combinable with existing energy sources
      • Exceptionally flexible
      • Minimum maintenance due to low-wear parts
      • Low ventilation loss
      • Lightweight construction
      • Minimized noise level
      • High durability

      BHS diaphragm couplings: light, reliable, powerful

        Voith diaphragm couplings are the result of unique know-how and decades of experience, which their reliable and exceptional performance reflects. As high-performance units, they convert high torque at high speeds despite their low weight.

        BHS diaphragm couplings: Also available as special models

          Our diaphragm couplings compensate for the axial, radial and angular misalignment of two coupled shafts. They are manufactured for torques of up to 1,500,000 Nm and speeds of up to 80,000 rpm. The standard program includes couplings for angular misalignment of up to 0.25°. Special models for angular misalignment of up to 0.5° are available upon request. Our high-performance couplings fulfill the requirements of API 671 as well as ISO 10441. They are approved for Zone 1 and Zone 2 in accordance with ATEX.

          Technical advantages of our diaphragm couplings

          Power transmission up to 70 MW
          Speeds up to 80,000 rpm
          Torque up to 1,500,000 Nm
          Design models
          • EconTors (single diaphragm)
          • TwinTors (double diaphragm)
          Connection type
          • inside hub
          • outside hub
          • flange
          Diaphragm-sleeve connection
          • bolted
          • welded
          • adhesive (CFRP sleeve)
          Meets standards
          • API 671
          • ISO 10441
          • ATEX, Zones 1 and 2
          Special models
          • torque-sensing spacer sleeve
          • lightweight design (CFRP)
          • low-windage design (optimized air flow characteristics)



          BHS diaphragm couplings: Free product consultation

            We are happy to provide all-round consultation on diaphragm couplings and other Turbo Gear units. This is why we give you free product advice. Once you send us your non-binding product inquiry, we will get back to you as soon as possible.

            Find your local contact

            In case of an emergency, dial +49 8321 802-555

            Well taken care of: Voith Service for your system

              Voith Service experts are always available to help you. From maintenance and repairs to modernization and exchanges, all the way to technical support, training, and more. Click the interactive icons to learn more about our services.

              24/7 Emergency Helpline

              Are you in need of emergency assistance? Our helplines are available around the clock.

              t +49 8321 802-555

              Voith services all brands

              Furthermore, our trained technicians are skilled in the servicing of other manufacturer brands.

              Find out more
