Voith BHS Planetary gear units

Powerful and compact

    Voith BHS planetary gear units

    Achieving high speeds and torque and known for efficient and long-term performance, Voith BHS planetary gears are powerful and compact. Built according to the Stoeckicht principle, these units enable ideal load equalization between the sun wheel, planetary, and ring gears. This load equalization ensures less stress on the components and dramatically reduces power loss in the gear unit.

    With more experience than any other firm in the market, we look forward to supplying powerful planetary gear units that will reduce operating costs over the long term.

    Get in touch with our experts VOITH SERVICE

    Features and benefits at a glance

      99
      Efficiency of max. 99.4 %
      80000
      Speeds of up to 80,000 rpm
      45
      Power transmission of up to 45 MW

      • Tailored to your technical requirements
      • Operational reliability, i.e., minimal unplanned stoppages of the drivetrain
      • Lower operating costs and reduced CO2 emissions
      • Achieving the highest mechanical efficiency for high gear ratios
      • ​​​​​​​Excellent load balancing, resulting from the Stoeckicht principle

      • Lower space requirement due to an inline arrangement
      • Compact, light, and space-saving drivetrains
      • High-quality gearing
      • Minimized noise level due to unique gear profiles
      • Long service life

      Ideal load equalization

        Achieving high speeds and torque and known for efficient and long-term performance, our planetary gears are built according to the Stoeckicht principle, which facilitates ideal load equalization between the sun wheel, planetary, and ring gears.

        Technical features

          With a high power density and low space and weight requirement, our planetary gear units ensure particularly favorable component stresses and transmit torques in turbo drivetrains efficiently and reliably. With an output of up to 45 MW, speeds of up to 80,000 rpm, and torques of over 550,000 Nm, our gear units easily meet high industry demands.

          Power transmissions up to 45 MW
          Speed up to 80,000 rpm
          Rated output torque up to 550,000 Nm
          Efficiency up to 99.4%
          Gear ratio

          up to i = 12 (single stage)
          up to i = 18 (compound star)
          up to i = 80 (two stage)

          Housing design free-standing casted (standard) and welded housings compact flange mounted E-Pack housings for your generator or electric motor
          Toothing double-helical (standard), spur
